Product Info
A wall mounted exposed riser rail in gunmetal, made from stainless steel for shower fittings.
The rail runs 710mm tall with a 72.5mm wall projection and a 116mm width, giving a shower handset long, adjustable travel up and down the wall.
Flow runs from 3.5 l/min at 0.2 bar up to 20.6 l/min at 5 bar, across a 0.5 to 5 bar working range through a 1/2" BSP inlet.
Key Features:
- Colour: Gunmetal
- Material: Stainless Steel
- Size: 116 x 710 x 72.5mm
- Installation: Wall mounted
- Flow: 20.6 l/min at 5 bar
- Inlet connection: 1/2" BSP
- Operating pressure: 0.5-5 bar
Product Specifications
Please note all measurements are in 'mm'
Overview:
Product Type: Slider Rails
Materials & Finish:
Colour: Gunmetal
Material: Stainless Steel
Construction Material: Stainless Steel
Colour / Finish: Gunmetal
Dimensions:
Width (mm): 116
Height (mm): 710
Depth (mm): 72.5
Specifications:
Installation type: Wall Mounted
WRAS Approved: No
TMV Approved: No
Minimum Operating Pressure (bar): 0.5
Maximum Operating Pressure (bar): 5
Inlet Connection: 1/2 BSP
0.2bar (l/min): 3.5
0.5bar (l/min): 6.1
1bar (l/min): 8.6
2bar (l/min): 12.4
3bar (l/min): 14.6
5bar (l/min): 20.6
Reviews
SKU: nu-083
Scudo Rainford Exposed Riser Rail, Hose & Outlet Elbow, Gunmetal
£105.00 GBP
