Product Info
Made in brass, the Core bath filler from Scudo is finished in Chrome, spanning 230mm wide and 130.5mm tall, deck mounted through 2 x 32mm tap holes with a single lever handle.
It runs on a quarter-turn cartridge fed by a 3/4 BSP inlet, delivering 9.8 litres a minute at 1 bar mains pressure across an operating range of 0.5 to 5 bar.
Key Features:
- Finish: Chrome
- Size: 230 x 130.5mm
- Material: Brass
- Installation: Deck mounted
- Tap holes: 2 x 32mm
- Flow rate: 9.8 l/min at 1 bar
Product Specifications
Please note all measurements are in 'mm'
Overview:
EAN: 5060766124483
Product Type: Bath Mixers
Range: Core
Manufacturer's Guarantee: Lifetime
Design & Appearance:
Style: Modern
Materials & Finish:
Colour: Chrome
Material: Brass
Construction Material: Brass
Colour / Finish: Chrome
Configuration & Options:
Number of Tap Holes: 2
Handle Type: Lever
Number of tap holes required: 2
Capacity & Flow:
Minimum Recommended Bar Pressure: 0.5 Bar
Maximum Recommended Bar Pressure: 5 Bar
Dimensions:
Width (mm): 230
Height (mm): 130.5
Depth (mm): 144mm
Length (mm): 144
Plumbing:
Waste Included: No
Tap Type description: Manual Mixer
Includes Waste: No
Specifications:
Installation type: Deck Mounted
WRAS Approved: Yes
Installation Type: Deck Mounted
Condition: New
TMV Approved: No
Minimum Operating Pressure (bar): 0.5
Maximum Operating Pressure (bar): 5
Inlet Connection: 3/4 BSP
0.2bar (l/min): 4
0.5bar (l/min): 7
1bar (l/min): 9.8
2bar (l/min): 13.6
3bar (l/min): 16.7
Flexible Tails Included: No
Swivel Spout: No
Valve / Cartridge Type: Quarter turn cartridge
Tap Hole Diameter (mm): 32
Tap Control: Twin Lever
