Images are for illustration purposes only
Product Info
Made in brass, the Core bath filler from Scudo spans 230mm across and stands 130.5mm tall, deck mounted through two 32mm tap holes.
A single lever handle sets flow and temperature through a quarter-turn cartridge, fed by a 3/4 BSP inlet.
Flow reaches 9.8 litres a minute at 1 bar and 16.7 at 3 bar, within a working range of 0.5 to 5 bar.
Key Features:
- Size: 230 x 130.5mm
- Material: Brass
- Installation: Deck mounted
- Tap holes: 2 x 32mm
- Inlet: 3/4 BSP
- Flow rate: 9.8 l/min at 1 bar
- Operating pressure: 0.5 to 5 bar
Product Specifications
Please note all measurements are in 'mm'
Overview:
EAN: 5060766124490
Product Type: Bath Mixers
Range: Core
Manufacturer's Guarantee: Lifetime
Design & Appearance:
Style: Modern
Materials & Finish:
Colour: Black
Material: Brass
Finish: Matt
Construction Material: Brass
Configuration & Options:
Number of Tap Holes: 2
Handle Type: Lever
Number of tap holes required: 2
Capacity & Flow:
Minimum Recommended Bar Pressure: 0.5 Bar
Maximum Recommended Bar Pressure: 5 Bar
Dimensions:
Width (mm): 230
Height (mm): 130.5
Depth (mm): 144mm
Length (mm): 144
Plumbing:
Waste Included: No
Tap Type description: Manual Mixer
Includes Waste: No
Specifications:
Installation type: Deck Mounted
WRAS Approved: Yes
Installation Type: Deck Mounted
Condition: New
TMV Approved: No
Minimum Operating Pressure (bar): 0.5
Maximum Operating Pressure (bar): 5
Inlet Connection: 3/4 BSP
0.2bar (l/min): 4
0.5bar (l/min): 7
1bar (l/min): 9.8
2bar (l/min): 13.6
3bar (l/min): 16.7
Flexible Tails Included: No
Swivel Spout: No
Valve / Cartridge Type: Quarter turn cartridge
Tap Hole Diameter (mm): 32
Tap Control: Twin Lever
